With UpMap, you can ensure maximum performance for your DUCATI PANIGALE V4 equipped with Termignoni 4USCITE (code D182).
This latest element completes the package dedicated to the latest Borgo Panigale model. For more information about the exclusive 4USCITE Racing Kit, visit the Termignoni website.
With UpMap, you can re-programme the ECU of your Panigale V4 to adjust engine calibration to the new D182 system, thereby getting the most out of the 4USCITE in terms of maximum performance as well as delivery and riding pleasure. A benefit that is clear right from the first twist of the throttle.
Ducati Panigale V4
CATEGORY: TERMIGNONI
Codice: V4-18-D182-FR
Designed for the Termignoni 4Uscite complete racing exhaust code D182, with deactivated lambda probes and exhaust valve. In terms of power, the mapping achieves 200.13 HP at 13,200 rpm with respect to the 186.78 HP of the original. In terms of torque, it records 11.85 Kgm at 11,200 rpm with respect to 11.06 Kgm of the original.
[Data cited refers to values at the wheel]
Technical data
| – | Original vehicle [values at the wheel] [HP] |
Termignoni 4 Uscite* [values at the wheel] [HP] |
Performance delta 4Uscite vs Original [HP] |
|---|---|---|---|
| Max. power (kW)** | 140.79 | 151.06 | + 10.3 |
| Max. power (hp)** | 191.42 | 205.38 | + 14.0 |
| Max. power engine speed (rpm)** | 13,000 | 13,400 | |
| Max. torque (kgm)** | 11.33 | 12.19 | + 0.86 |
| Max. torque (Nm)** | 111.1 | 119.5 | + 8.4 |
| Max. torque engine speed (rpm)** | 9600 | 11,200 |
* Complete kit without db Killer and with UpMap installed
** values recorded with STD standard correction factor
Incremento prestazionale per regime
| Speed [rpm] | Original vehicle [values at the wheel] [HP] |
Termignoni 4Uscite* [values at the wheel] [HP] |
Performance Delta 4Uscite vs Original [Cv] |
Performance Delta 4Uscite vs Original[%] |
|---|---|---|---|---|
| 14’000 | 184.4 | 203.8 | + 19.4 | + 11% |
| 13’500 | 190.4 | 205.4 | + 15.0 | + 8% |
| 13’000 | 191.4 | 202.2 | + 10.8 | + 6% |
| 12’500 | 188.5 | 201.1 | + 12.6 | + 7% |
| 12’000 | 187.4 | 198.6 | + 11.3 | + 6% |
| 11’000 | 169.5 | 186.3 | + 16.8 | + 10% |
| 10’000 | 156.3 | 165.9 | + 9.6 | + 6% |
| 9’000 | 137.5 | 144.8 | + 7.3 | + 5% |
| 8’000 | 116.8 | 122.8 | + 6.0 | + 5% |
| 7’000 | 91.1 | 97.0 | + 5.9 | + 6% |
| 6’000 | 75.1 | 78.6 | + 3.4 | + 5% |
| 5’000 | 61.3 | 65.6 | + 4.3 | + 7% |
| 4’000 | 46.4 | 49.9 | + 3.5 | + 8% |
We remind you that the new mapping and new Firmware for TD800 rel. 1.2.37.117 dedicated to your Panigale V4 equipped with 4USCITE is included in the Racing Kit for the D182 complete exhaust.
Don’t delay, download it from our STORE now.
UpMap – Next Level for Passion
